Single 12" Two-Way Multi-Purpose Full-Range Speaker

JG-2012
JG-2012
JG-2012
JG-2012
JG-2012
JG-2012
JG-2012
JG-2012

12" High-Power, Ultra-Low Distortion Bass

  • The Audio JG-2012 is a 2-way versatile full-range speaker system with a balanced rear-ported enclosure. It features a built-in 12" high-power, ultra-low distortion woofer and a 90°x60° PU horn with a 1" throat professional tweeter driver.
Contact us

Main Features

  • Rated Power: 450W (AES)
  • Peak Power: 1800W (AES)
  • Input Connection: 1×NeutrikTM 1+ 1-
  • Sensitivity: 95dB
  • Maximum Sound Pressure Level: 126dB
  • Nominal Impedance: 8Ω
  • Dispersion Angle: 90°×60°
  • Net Weight: 21.7Kg
  • Enclosure Dimensions: 385mm×610mm×388mm (W×D×H)

Product Description

The Audio JG-2012 is a 2-way multi-purpose full-range speaker system featuring a balanced rear-ported enclosure, equipped with a 12" high-power, ultra-low distortion woofer and a 90°x60° PU horn with a 1" throat professional tweeter. As a 2-way system, the JG-2012 can be driven directly or paired with a bi-amplification system for superior high output performance. It is an ideal audio solution for fixed installations, high-end KTVs, nightclubs, mid/near-field sound reinforcement, or private clubs.

Technical Specifications


Type: 2-Way Full-Range Multi-Purpose Loudspeaker System
Frequency Response: 42Hz-20kHz
Power: 450W
Peak Power: 1800W
Impedance: 8Ω
Dispersion Angle: 90° × 60°
Sensitivity: 95dB
Maximum SPL: 126dB
Crossover Frequency: 1.5kHz (Built-in Crossover)
Input Connector: 1×NeutrikTM 1+1-
Low-Frequency: 12" Woofer with a custom-designed low-frequency unit from a Sino-British joint venture, 3" (75mm) voice coil, rated power: 450W (AES)
High-Frequency: 1" throat, compression driver with a custom-designed high-frequency unit from a Sino-British joint venture, 1.75" (44mm) voice coil, rated power: 80W (AES)
Enclosure Material: 15mm High-Density MDF
Enclosure Finish: Eco-friendly water-based paint
Net Weight: 21.7Kg
Dimensions: 385mm×610mm×388mm (W×D×H)
