KA-10

3-unit 2-way multi-purpose full-range Karaoke speaker system

KA-10
KA-10
KA-10
KA-10
KA-10
KA-10
KA-10
KA-10
KA-10

10" high-power ultra-low distortion Bass

  • The Audio KA-10 is a balanced front-ported cabinet, equipped with one 10-inch high-power, ultra-low distortion woofer and two 3-inch full paper cone tweeters with a 120°x60° dispersion angle.
Contact us

Main Features

  • Rated Power: 250W (AES)
  • Peak Power: 1000W (AES)
  • Input Connection: Black and Red Binding Posts
  • Sensitivity: 95dB
  • Maximum Sound Pressure Level: 123dB
  • Nominal Impedance: 8 Ohms
  • Dispersion Angle: 90° Conical
  • Net Weight: 11.9Kg
  • Enclosure Dimensions: 505mm*270mm*295mm (W*D*H)

Product Description

The Audio KA-10 is a balanced front-ported enclosure featuring a built-in 10" high-power, ultra-low distortion woofer and two 3" full-paper cone tweeters, forming a 120°x60° versatile full-range speaker system. As a 2-way system, the KA-10 can be paired with a bi-amplification system to achieve optimal high output. The Audio KA-10 is an ideal powerful solution for commercial KTVs, nightclubs, and corporate events.

Technical Specifications


Type: 2-Way Full-Range Multi-Purpose Speaker System
Frequency Response: 45Hz-16kHz
Power: 250W
Peak Power: 1000W
Impedance: 8Ω
Dispersion Angle: 90° conical
Sensitivity: 95dB
Maximum SPL: 123dB
Crossover Frequency: 1.5kHz built-in crossover
Input Connector: Red and black binding posts
Low Frequency: 10" woofer with Malaysian-imported paper cone, 2.35" (60mm) voice coil, rated power: 250W (AES)
High Frequency: 3"x2 tweeter with Malaysian-imported paper cone, 0.55" (14mm) voice coil, rated power: 15W (AES)
Enclosure Material: Domestic high-density MDF
Enclosure Finish: Black PVC vinyl
Net Weight: 11.9Kg
Dimensions: 505mm*270mm*295mm (W*D*H)
