KA-12

5-unit 2-way multi-purpose full-range KaraOK speaker system

KA-12
KA-12
KA-12
KA-12
KA-12
KA-12
KA-12
KA-12

12" high-power ultra-low distortion bass driver

  • The Audio KA-12 is a balanced front-ported enclosure featuring a built-in 12" high-power, ultra-low distortion woofer and four 3" full-range paper cone tweeters. It is an 80°x50° multi-purpose full-range speaker system.
Contact us

Main Features

  • Rated Power: 350W (AES)
  • Peak Power: 1440W (AES)
  • Input Connection: Red and black binding posts
  • Sensitivity: 96dB
  • Maximum SPL: 126dB
  • Nominal Impedance: 8Ω
  • Dispersion Angle: 90° conical
  • Net Weight: 17.35 kg
  • Enclosure Dimensions: 565mm * 360mm * 315mm (W*D*H)

Product Description

The Audio KA-12 is a balanced front-ported enclosure featuring a built-in 12" high-power, ultra-low distortion woofer and four 3" full-range paper cone tweeters. It is an 80°x50° versatile full-range speaker system.

Technical Specifications


Type: 2-way full-range versatile speaker system
Frequency Response: 42Hz-16kHz
Power: 350W
Peak Power: 1400W
Impedance: 8Ω
Dispersion Angle: 90° conical
Sensitivity: 96dB
Maximum SPL: 126dB
Crossover Point: 1.8Hz built-in crossover
Input Connector: Red and black binding posts
Low-Frequency: 12" paper cone driver with Malaysian-origin components, 2.55" (65mm) voice coil, rated power: 350W (AES)
High-Frequency: 4x 3" paper cone tweeters with Malaysian-origin components, 0.55" (14mm) voice coil, rated power: 15W (AES)
Enclosure Material: Domestic high-density MDF
Enclosure Finish: Black PVC vinyl
Net Weight: 17.35 kg
Dimensions: 565mm * 360mm * 315mm (W*D*H)
