LY-12

Single 12" two-way multi-purpose full-range Loundspeaker

LY-12
LY-12
LY-12
LY-12
LY-12
LY-12
LY-12
LY-12

12" High-power, ultra-low distortion bass

  • The Audio LY-12 is a 2-way multi-purpose full-range speaker system featuring a trapezoidal front-ported enclosure. It is equipped with a built-in 12" high-power, ultra-low distortion woofer and a 90°x60° rotatable square fiberglass horn with a 1.5" throat compression driver.
Contact us

Main Features

  • Rated Power: 500W (AES)
  • Peak Power: 2000W (AES)
  • Input Connection: 2*Neutrik? 1+1-
  • Sensitivity: 96dB
  • Maximum Sound Pressure Level: 129dB
  • Nominal Impedance: 8 Ohms
  • Dispersion: 90° X 60°
  • Net Weight: 25.7Kg
  • Dimensions: 367mm*590mm*385mm (W*H*D)

Product Description

The Audio LY-12 is a trapezoidal front-ported enclosure featuring a built-in 12" high-power, ultra-low distortion woofer and a 90°x60° rotatable square fiberglass horn with a 1.5" throat compression driver, making it a versatile 2-way full-range speaker system. As a 2-way system, the LY-12 can be driven directly or paired with a dual-channel amplifier system to achieve excellent high output. The Audio LY-12 is designed to provide audio solutions for high-end KTVs, nightclubs, VIP rooms, and mid/near-field stage monitoring applications.

Technical Specifications


Type: 2-Way Full-Range Multi-Purpose Loudspeaker System
Frequency Response: 45Hz-20kHz
Power: 500W
Peak Power: 2000W
Impedance: 8Ω
Dispersion Angle: 90° X 60°
Sensitivity: 96dB
Maximum SPL: 129dB
Crossover Frequency: 1.3kHz Built-in Crossover
Input Connectors: 2*NeutrikTM 1+1-
Low-Frequency: 12" Woofer with European Custom Bass Unit, 3" (75mm) Voice Coil, Rated Power: 500W (AES)
High-Frequency: 1" Throat Compression Driver with European Custom Unit, 1.75" (44.4mm) Voice Coil, Rated Power: 70W (AES)
Enclosure Material: 15mm + 18mm Marine-Grade Birch Plywood
Enclosure Finish: Black Polyurea Paint
Net Weight: 25.7Kg
Dimensions: 367mm*590mm*385mm (W*H*D)
