- Rated Power: 600W (AES)
- Peak Power: 2400W (AES)
- Input Connectors: 2×NeutrikTM 1+1-
- Sensitivity: 100dB
- Maximum SPL: 134dB
- Nominal Impedance: 8Ω
- Dispersion: 80° × 50°
- Net Weight: 32.4kg
- Dimensions: 439mm × 700mm × 407mm (W×H×D)
Single 15" two-way multi-purpose full-range Loundspeaker
Audio LY-15 is a trapezoidal front-ported enclosure featuring a built-in 15" high-power, ultra-low distortion woofer and an 80°x50° rotatable square fiberglass horn with a 1.5" throat compression driver, making it a versatile 2-way full-range loudspeaker system. As a 2-way system, the LY-15 can be driven directly or paired with a dual-channel amplifier system to achieve excellent high output.
The Audio LY-15 is suitable for providing sound reinforcement solutions in venues such as bars, lounges, nightclubs, and mid/near-field applications.
| Type: | 2-Way Full-Range Multi-Purpose Loudspeaker System |
|---|---|
| Frequency Response: | 42Hz-20kHz |
| Power: | 600W |
| Peak Power: | 2400W |
| Impedance: | 8Ω |
| Coverage Angle: | 80° X 50° |
| Sensitivity: | 100dB |
| Maximum SPL: | 134dB |
| Crossover Point: | 1.2kHz Built-in Crossover |
| Input Connectors: | 2*NeutrikTM 1+1- |
| Low-Frequency: | 15" Woofer with European Customized Bass Unit, 3.2" (80mm) Voice Coil, Rated Power: 600W (AES) |
| High-Frequency: | 1" Throat Compression Driver with European Customized Unit, 3" (75mm) Voice Coil, Rated Power: 150W (AES) |
| Enclosure Material: | 15mm Marine-Grade Birch Plywood |
| Enclosure Finish: | Black Polyurea Paint |
| Net Weight: | 32.4Kg |
| Dimensions: | 439mm*700mm*407mm (W*H*D) |
