HX-12D

Single 12" Two-Way Multi-Purpose Full-Range Speaker

12" High-Power, Ultra-Low Distortion Bass

The Audio HX-12D speaker features a built-in 12" high-power, ultra-low distortion woofer and a 90°x60° rotatable square fiberglass composite horn.

Main Features

Rated Power: 450W (AES)
Peak Power: 1800W (AES)
Input Connector: 1×Neutrik^TM 1+1-
Sensitivity: 96dB
Maximum SPL: 126dB
Nominal Impedance: 8Ω
Dispersion Angle: 90°×60°
Net Weight: 22.1Kg
Enclosure Dimensions: 351mm×575mm×353mm (W×D×H)

Description
Specifications

Product Description

The Audio HX-12D speaker features a built-in 12" high-power, ultra-low distortion woofer and a rotatable 90°x60° square fiberglass horn with a 1" throat compression driver, forming a 2-way multi-purpose full-range speaker system. As a 2-way system, the HX-12D can be paired with a dual-channel amplifier system to achieve high output performance.
The Audio HX-12D is suitable for fixed installations, banquet halls, conference rooms, bars, lounges, and private clubs, providing sound reinforcement solutions for near/mid-field applications.

Technical Specifications

Type:	2-Way Full-Range Multi-Purpose Speaker System
Frequency Response:	52Hz-20kHz
Power:	450W
Peak Power:	1800W
Impedance:	8Ω
Dispersion Angle:	90°×60°
Sensitivity:	96dB
Maximum SPL:	126dB
Crossover Point:	1.5kHz (Built-in Crossover)
Input Connector:	1×Neutrik^TM 1+1-
Low-Frequency:	12" Woofer with European custom-designed bass driver, 3" (75mm) voice coil, rated power: 450W (AES)
High-Frequency:	1" Throat, European custom-designed compression driver, 1.75" (44mm) voice coil, rated power: 80W (AES)
Enclosure Material:	15mm Marine-Grade Birch Plywood
Enclosure Finish:	Black Water-Based Paint
Net Weight:	22.1Kg
Dimensions:	351mm×575mm×353mm (W×D×H)
