Effects & Digital Loudspeaker Management & Microphone

V5 Effects

V5 is applicable to KTV digital front stage, karaoke room, the requirements of the simple dance halls, conference rooms and multi-function hall, It is so popular because of its good effect, easy to operate, cost-effective. The product which has the function of speaker processor karaoke effect, function of each part are adjustable independently, It is easy to operate that have corresponding PC interface

A-II Effects

A - II is a 5.S brand special effector with six-way output processor for audio effects. With Hi-Fi-leveled audio output, A - II is an excellent mid frequency performer, and it integrates fine high-frequency extension and powerful and elastic low-frequency limit to produce perfect and balanced timber, thus enabling 5.S Audio loudspeaker to perform its best. The audio and power filter capacitor of A - II applies imported technologies from Germany. With elaborate material selection and delicate debugging, A - II possesses ultra-high stability and produces precise sound, thus making the best singing effect out of an enclosure in a private entertainment room in KTV clubs.

GT-259A Wireless Microphone

1.GT-259A microphone is a new concept of intelligent, automated wireless microphone.
2.Automatic hand-sensing patented technology, the microphone to leave the staff within 3 seconds after the static mute.
3.Five minutes after the automatic energy-saving standby mode,fifteen minutes after the automatic shutdown and completely cut off the power.
4.Treble delicate, strong in the low-frequency, especially in the details of the sound with the perfect expression.
5.The super dynamic tracking capabilities, making the far and close up and pick up freely.
6.The new concept of digital pilot technology, can be completely solved the KTV rooms with each other string frequency phenomenon.
7.Equipped with the noise suppression function circuit,automatically search for interference-free channel function, easier installation and commissioning.
8.UHF band, phase-locked loop (PLL) frequency synthesis, 100 × 2 channels, the channel spacing 250KHz.
9.Infrared automatic frequency function, the microphone can be quickly synchronized to the receiver's working channel.

S2 Wireless Microphone

1.S2 microphone is a new concept of intelligent, automated wireless microphone.
2.Automatic hand-sensing patented technology, the microphone to leave the staff within 3 seconds after the static mute.
3.Five minutes after the automatic energy-saving standby mode,fifteen minutes after the automatic shutdown and completely cut off the power.
4.Treble delicate, strong in the low-frequency, especially in the details of the sound with the perfect expression.
5.The super dynamic tracking capabilities, making the far and close up and pick up freely.
6.The new concept of digital pilot technology, can be completely solved the KTV rooms with each other string frequency phenomenon.
7.Equipped with the noise suppression function circuit,automatically search for interference-free channel function, easier installation and commissioning.

X-10 Wireless Microphone

X-10 Wireless Microphone5.S Audio X-10 is a true diversity microphone, the effective receiving distance can reach 100 meters, suitable for conferences, performances, banquet halls and other places.

K-300 Wireless Microphone

K-300 Use Industry automatic induction hand patent technology, left hand phone static 3 secondsautomatically mute (any direction, place both at any Angle), automatic energy saving after 5minutes, 15 minutes and automatic shutdown completely cut off the power, is a new conceptof the intelligent and automatic. The wireless microphone。

A-8 Effects

A8 using the latest ADI five series chips, 64-Bit high-speed dual-core DSP processorMusic channel has 9 segments of PEQ stereo equalizer, and automatic recognitionofoptical fiber audio digitalinput.
The microphone has 15 PEO single adjustment, full digital audio processing system,stereo DSP multiple digital reverberation, more professional voice effect.Microphone has muffler setting, independent pressure limit design; Frequency shift:2Hz ~ 8Hz feedback suppression is optional, and "OFF"is optional.
The effect channelis independent with high and low pass. Reverberation and echo arerespectively set with 5 parameters equalization (PEQ)

A-IV Effects

Adopting the latest and highest performance ADI 5 series processing chips on the market, the computing speed will be faster and more accurate, and the sound effect will be greatly improved. Computer software with professional level RTA spectrum display, it is more accurate and intuitive for prevent the noise frequency point and more convenient to debug! Bass is thick and clean, intermediate frequency is wide and transparent, treble is clear and delicate.

S3 Wireless Microphone

Frequency Range UHF640一690MHz Channels,200CH

Frequency Interval 250KHz

Effective use distance 30m

Frequency width, 50MHz

RECEIVER

Noise ratio ≥ 50dB

Receiving method CPU Control selection and pilot identification reception Silent mode, Mute & Lock Loop Circuit

Display method LCD

Power supply 12V DC 1250mA

Audio output interface,Unbalanced TRS 6.35mm Socket

HANDHELD

Frequency range, UHF 640一690MHz

Channels, 200CH

Frequency interval,250KHz Frequency width,50MHz

Display method LCD+ Blue backlist screen Capsule type: dynamic coil

two level power :high， low

DAP4080III

▼400MHZ main frequency, 32 bit floating, 96KHz sampling frequency, 24 bit A/D or D/A converter, high S/N;
▼Models: 2 in 4 out, 2 in 6 out, 4 in 6 out, 4 in 8 out;
▼31 bands GEQ and 10 bands PEQ, gain, polarity, mute and delay are for each input Channel;
▼10 bands PEQ, HPF, LPF, gain, polarity, delay, compressor and mute are for output Channels;
▼Input/output channels can be linked to set synchronously, max delay: 1000ms;
▼HPF/LPF:Bessel/Butterworth(12dB/oct,18dB/oct,24dB/oct),Linkwitz-Riley(12dB/oct, 24dB/oct, 36dB/oct, 48dB/oct);
▼RS485 can connect 250 machines and support remote control beyond 1500 meters;
▼RS232 supports central control;
▼Panel lock function to avoid any misoperation;
▼12 groups user settings;
▼Equipped with professional PC software.
