5.S Audio applies to use in concerts/bars/clubs


5.S D-SERIES manifold applications in art performance/dramshop/clubs

5.S Audio applies to use in big gymnasium


5.S D-SERIES products are widely use in various types of gymnasiums where amplification provided.

5.S Audio


Perfect Sound, Great Enjoyment!

5.S Series for conference


5.S JS SERIES/TT SERIES is intended for use in airports, shopping malls and conference halls, where the demands of the sound amplification must met.





D SERIES

D series is a highly compact two-way/three-way line array amplification system. High power continuous output, stable dynamic performance, together with precise and perfect high frequency sound amplification, precise scale simplicity and domineering, and humanized operation connectors, it has become the most favorite for indoor and outdoor performance. The enclosure is made of Birch Plywood from North European, and the surface is protected by Polyurea Paint which has waterproof, sun protection and scratch resistant advantages. The enclosure connector adopts the international standard aluminum with a one piece precision processing and precise scale on the engraving, and makes the sound amplification extremely accurate. The enclosure input port is a fixed interface that using international aircraft-grade professional ten core screw tooth. The connector is international standard pure copper plating with high technology, which minimize the loss. The tweeter and woofer use customized neodymium originally imported from European with perfect HF control. The neodymium compression driver is installed in a unique straight horn, with unique design of compressed driver makes the throat gap smallest to avoid the HF interference. The woofer use powerful neodymium with the most advanced radiator design to ensure the sound smooth after dynamic work for a long time. Because of high control and precise woofer frequency, and with the optimal design of the cooling system, which ensure the voice coil with high permeability and the power with max. handling capacity.

Features

  • High SPL output with multi-functional full range loudspeaker system with 3-way design
  • 1" or 1.5"horn unique design, customized neodymium originally imported from the European
  • Unique design of straight horn
  • 8” & 10" & 12"ultra-low distortion of bass unit
  • Full-frequency dual channel or four channel amplifier drive
  • Design for use in fixed installations, auditorium, banquet hall, gymnasium and performance etc.

D SERIES

D-208 Line-Array FullRange LoudSpeaker

5. S Audio D - 208 is a multi-functional full range loudspeaker system with 2-way design, built into two voice coil of 8 "60 mm, equipped with a high power ultra-low distortion neodymium bass unit, a 1.5" throat of 120 ° x20 TB-C horn, and 75mm voice coil neodymium compression driver unit. The treble and woofer is the customized unit originally imported from Europe with flexibility professional hanger. As a 2-channel system, D-208 can be either driven directly or matched with a dual-amplifier system to achieve extremely high output. Ideal for use in gymnasium, auditorium, hotel conference, theater, large - scale activities, and provide professional audio solutions.

D-210 Line-Array FullRange LoudSpeaker

5. S Audio D - 210 is a multi-functional full range loudspeaker system with 2-way design, built into two voice coil of 10 "75 mm, equipped with a high power ultra-low distortion neodymium bass unit, a 1.5" throat of 90 ° x60 TB-C horn, and 75mm voice coil neodymium compression driver unit. The treble and woofer is the customized unit originally imported from Europe with flexibility professional hanger. As a 2-channel system, D-210 can be either driven directly or matched with a dual-amplifier system to achieve extremely high output. Ideal for use in gymnasium, auditorium, hotel conference, theater, large - scale activities, and provide professional audio solutions.

D-212 Line-Array FullRange LoudSpeaker

5. S Audio D - 212 is a multi-functional full range loudspeaker system with 2-way design, built into two voice coil of 12 "85 mm,  equipped with a high power ultra-low distortion neodymium bass unit, with four 6"high-power of ultra-low distortion midrange unit, two 1" throat of 120 ° x20 TB-C horn, and 45mm voice coil neodymium compression driver unit. The treble and woofer is the customized unit originally imported from Europe with flexibility professional hanger. As a 2-channel system, D-212 can be either driven directly or matched with a dual-amplifier system to achieve extremely high output. Ideal for use in gymnasium, auditorium, hotel conference, theater, large - scale activities, and provide professional audio solutions.

D-115B FullRange & Bass Loudspeaker

5. S Audio D-115B is a multi-functional low frequency loudspeaker system, built into a 10 "65 mm voice coil, equipped with a high power ultra-low distortion neodymium bass unit and a 75mm voice coil. The woofer is the customized unit originally imported from Europe and with flexibility professional hanger. As a one-way system, D-115B can be either driven directly or matched with a dual-amplifier system to achieve extremely high output. Matching with D-208 to use in gymnasium, auditorium, flowing performance, theater and large - scale activities, and provide professional audio solutions.

D-215B FullRange & Bass Loudspeaker

5. S Audio D-215B is a multi-functional low frequency loudspeaker system, built into two voice coil of 15 "100 mm, equipped with a high power ultra-low distortion neodymium bass unit. The woofer is the customized unit originally imported from Europe and with flexibility professional hanger. As a one-way system, D-215B can be either driven directly or matched with a dual-amplifier system to achieve extremely high output. Ideal for use in gymnasium, auditorium, flowing performance, theater, large - scale activities, and provide professional audio solutions.

D-218B FullRange & Bass Loudspeaker

5. S Audio D-218B is a multi-functional low frequency loudspeaker system, built into two voice coil of 18 "100 mm, equipped with a high power ultra-low distortion neodymium bass unit. The woofer is the customized unit originally imported from Europe and with flexibility professional hanger. As a one-way system, D-218B can be either driven directly or matched with a dual-amplifier system to achieve extremely high output. Ideal for use in gymnasium, auditorium, flowing performance, theater, large - scale activities, and provide professional audio solutions.
